Technical parameters

1. Smooth appearance, uniform color, fastness

2.  Nominal voltage ：220V  50Hz  ：Customizable

3.  Rated current : 27±5mA

4. Insulation grade : E grade

5. Apply pressure : 0.02-1.0MPa

6. Maximum resistance to water pressure: Less than 2.0MPa, no leakage after 10min

7. Flow requirements :  ( Customizable )

8. Coil resistance : 4.7±0.3KΩ

9. The service life not less than 30000 times, at room temperature, power on for 5 seconds at rated voltage, and power off for another 5 seconds is one cycle :(1) at 0.02MPa, 50000 times;(2) at 0.3mpa, 20000 times;(3) at 0.8mpa, 5000 times

The coil should not be burnt out after 8 hours of continuous electrification.
